GridPin

A country in a file — offline forward and reverse geocoding.

Quick start

$ pip install gridpin gridpin-mcp
$ gridpin-fetch fr    # France sheet, 365 MB, checked against the signed release; prints its path

import gridpin
from gridpin_mcp import sheets

g = gridpin.Geocoder(str(sheets.download("fr")))  # no-op once the sheet is downloaded
g.geocode("1 rue de la Paix, Paris", 1)

No install: try it in Colab — the Serbia sheet, forward, reverse and batch geocoding in five minutes.

Countries: br de es fr it nl rs (gridpin-fetch --list). For AI agents there is an MCP server — claude mcp add gridpin -- uvx gridpin-mcp, details in mcp/README.md. Everything after the download runs offline.

GridPin is an offline geocoder: a country in a data file, memory-mapped and ready in milliseconds, with no server, no database import, and no network. It resolves addresses to coordinates (forward) and coordinates to the nearest indexed address (reverse — approximate: streets are indexed by centroid, so each result carries its distance_m). On a single arm64 laptop core, measured on the France sheet: exact address lookups run at ~3,000/s, reverse geocoding at ~1,800/s, and typo-tolerant fuzzy matching much slower — tens of milliseconds per query, so batch it across cores when you feed it messy input. The engine and every query run fully offline — not a byte of what you geocode leaves your machine; the only network step is you downloading a sheet yourself, and a downloaded sheet carries no query data. Because you compute results locally from openly licensed data, you may store them forever, which hosted geocoding APIs typically forbid. If you have considered self-hosting Nominatim (a beefy server, days of import) or an on-prem geocoder license, the alternative here is: download one file, open it on any laptop.

Install

CLI — prebuilt binaries for Linux x86_64 (x86_64-unknown-linux-gnu), macOS Apple Silicon (aarch64-apple-darwin) and Windows x86_64 (x86_64-pc-windows-msvc) are attached to every GitHub release; other targets (Intel macOS, Linux arm64/musl, Windows arm) build from source:

$ base=https://github.com/gridpin/gridpin/releases/download/v0.4.0
$ curl -fsSLO "$base/gridpin-aarch64-apple-darwin.tar.gz"
$ curl -fsSLO "$base/gridpin-release-signers"
$ curl -fsSLO https://dl.gridpin.dev/v0.4.0/attestation.json
$ curl -fsSLO https://dl.gridpin.dev/v0.4.0/attestation.json.sig
# the trust root comes from the OTHER channel — see "Verifying a release" for why
$ ssh-keygen -Y verify -f gridpin-release-signers -I gridpin-release \
    -n gridpin-g02 -s attestation.json.sig < attestation.json \
    || { echo "signature does not verify — STOP"; exit 1; }
$ want=$(python3 -c 'import json;print([a["sha256"] for a in json.load(open("attestation.json"))["assets"] if a["name"]=="gridpin-aarch64-apple-darwin.tar.gz"][0])')
$ test "$want" = "$(shasum -a 256 gridpin-aarch64-apple-darwin.tar.gz | cut -d' ' -f1)" \
    || { echo "archive does not match the signed attestation — STOP"; exit 1; }
$ tar xzf gridpin-aarch64-apple-darwin.tar.gz && sudo mv gridpin /usr/local/bin/

Yes, that is longer than curl | tar. Unpacking an archive runs its contents sooner or later, and a checksum published beside the file it describes proves only that the download was not truncated — whoever can replace one can replace both. The four extra lines are what makes it a check.

Or build from source with stable Rust: cargo build --release --manifest-path gridpin/Cargo.toml.

Python — pip install gridpin. This one rests on PyPI's own integrity, not on the signature above: the attestation covers the artifacts we publish ourselves. If you need the signed chain, take the wheel from the GitHub release and verify it the same way as the CLI archive.

DuckDB — INSTALL gridpin_ext FROM community; then LOAD gridpin_ext;. The community catalog builds and signs the extension itself, so that trust root is DuckDB's rather than ours; it needs DuckDB 1.5.5 or newer. On an older DuckDB, or when the catalog is unreachable, download gridpin_ext-<platform>.zip from the releases page. It is a loadable extension, so authenticate it before you load it — same three lines as the CLI archive above, with gridpin_ext-<platform>.zip as the asset name:

$ ssh-keygen -Y verify -f gridpin-release-signers -I gridpin-release \
    -n gridpin-g02 -s attestation.json.sig < attestation.json \
    || { echo "signature does not verify — STOP"; exit 1; }
$ want=$(python3 -c 'import json;print([a["sha256"] for a in json.load(open("attestation.json"))["assets"] if a["name"]=="gridpin_ext-osx_arm64.zip"][0])')
$ test "$want" = "$(shasum -a 256 gridpin_ext-osx_arm64.zip | cut -d' ' -f1)" \
    || { echo "extension does not match the signed attestation — STOP"; exit 1; }

Then unzip it and LOAD the extracted gridpin_ext.duckdb_extension in a duckdb -unsigned session — keep that basename, DuckDB derives the entry symbol from it.

Quick start

CLI

# forward: address -> coordinates, top 3 candidates
$ gridpin query france.bin "1 rue de la Paix Paris" -k 3

# reverse: coordinates -> nearest indexed address (approximate; each hit carries distance_m)
$ gridpin reverse france.bin 48.8686 2.3305

# batch: JSONL in ({"q": "..."} per line), JSONL out
$ gridpin batch france.bin queries.jsonl results.jsonl -k 1

Python

$ pip install gridpin

import gridpin

g = gridpin.Geocoder("france.bin")
g.geocode("1 rue de la Paix Paris", 1)
g.reverse(48.8686, 2.3305, 1)

The wheel wraps the Rust engine directly (pyo3/maturin); on a single core, exact lookups run at ~3,000/s, while typo-heavy input is fuzzy-matched at tens of milliseconds per query — use geocode_many() to batch across cores.

DuckDB

The gridpin_ext extension exposes five functions: gridpin_load, gridpin_load_poi (optional POI layer), gridpin_reset, gridpin_geocode, gridpin_reverse. One country per session — the loaded path may not change while it is loaded (a different path is an error, so a path column can never swap the index in the middle of a running query); to switch countries run SELECT gridpin_reset(); (a standalone statement — it refuses to run inside a multi-row query) and load the new sheet. The loaded sheet is shared by every connection to the same database process: coordinate switches externally when several connections query concurrently.

LOAD gridpin_ext;
SELECT gridpin_load('france.bin');
SELECT gridpin_geocode(address)  FROM orders;
SELECT gridpin_reverse(lat, lon) FROM pings;

Countries & data

A country in a file — most countries are a single file (a few regional datasets add a small companion file, and the optional POI layer is its own file). We call a country file a sheet, the full set an atlas, and a monthly data release fresh sheets.

Germany covers 15 of 16 Länder; Bavaria is not covered. In local spot checks, Bavarian queries typically returned a distant same-named address with low confidence; less often, an empty answer. Neither outcome establishes coverage. These spot checks illustrate failure modes, not population rates. The release sheet contains 19,267,049 addresses, 213,315,143 bytes, and no POI layer. Per-Land providers and licenses are in ATTRIBUTIONS.md.

POI coverage is per-country (see the table; we ship a layer only where source data is rich enough to help). For France, pass the layer and the engine cascades automatically — address index first, POI only on weak results, exact addresses never overridden: gridpin query france.bin "pharmacie gare de Lyon" --poi fr_poi.bin or gridpin.Geocoder("france.bin", poi="fr_poi.bin").

The cascade precedence, identical for free-form and structured input:

Structured input feeds EVERY provided token to the POI escalation, joined in the canonical street number postcode city order — a number is often part of a place name ("Studio 54"). The two input styles agree on the winner for address resolution and for POIs whose tokens are in that canonical order. They can differ only when the fields you supply reorder the words of an order-sensitive POI name (splitting "54 Studio" into street:"studio", number:"54" re-forms it as "Studio 54"); pass such a query as free-form to keep the original word order.

Sizes are for v7 builds (August 2026; Germany repacked 2026-09-10; Spain added 2026-09-28; Brazil added 2026-10-11); the exact byte sizes are checked against a pinned source of truth in CI. A sheet is smaller than its own raw source: France's registry download is an 885 MB gzip that unpacks to 4.9 GB of CSV, while the finished sheet — the same 26.1M addresses plus every index (typo automata, spatial cells, ranking) — is 365 MB, ready to query.

Download sheets. Free builds of all available countries are served as individual files — there is no directory listing, so link straight to the object you want: france.bin (365 MB), germany.bin (213 MB), italy.bin (247 MB), netherlands.bin (103 MB), serbia.bin (32 MB), spain.bin (185 MB), brazil.bin (677 MB), plus the optional France POI layer fr_poi.bin (231 MB). The matching SHA256SUMS manifest (covering the engine binary and every sheet) is on the GitHub release. Subscribers fetch fresh monthly builds from a keyed URL instead — see gridpin.dev/docs.

Quality

GridPin is built for addresses as people type them — typos, shortened street types, missing commas, the town written first. Share of queries whose first answer lands within 150 m of an independent reference coordinate (empty answers count as misses):

Distorted means each real address was changed by one fixed mechanical rule, with the reference coordinate kept byte for byte. On German and Spanish distorted addresses GridPin leads both services; on Brazilian distorted addresses GridPin and Photon are level, both well ahead of Nominatim; on clean German addresses GridPin and Photon are level (p=0.6691367 — not proof of parity). We show the sets where GridPin leads or is level; on the other Spanish sets Photon leads, and on clean Brazilian addresses Photon leads too. Counts, paired tests and data fingerprints for every set are in docs-public/BENCHMARK.md; the summary lives on the test bench page.

Compatibility. GridPin answers in the Photon API format, forward and reverse (the reverse endpoint is implemented since 2026-08-06). On the external geocoder-tester suite — a compatibility fixture set, not an accuracy oracle — the full official Alsace numbered-address file passes 230/285 (2026-08-07; 0 → 173 → 208 → 230 as the adapter matured).

Two more axes where the comparison is not close: speed — ~3,000 exact lookups per second on a single arm64 core, with no network round-trip — and cost and privacy: no per-query fee at any volume, and not one query leaves your machine.

CI runs cargo test on three operating systems, plus a public smoke test that builds a tiny Monaco sheet from an OSM extract and runs live queries against it.

How it works

A country sheet is a single self-contained index file designed to be memory-mapped: opening it is effectively instant, there is no import into a database and no daemon to keep warm, and the first query returns in milliseconds from a cold start. Inside the file, sections are laid out for lazy access: an FST over the normalized lexicon for exact and prefix matching, spatial cells for reverse lookup and proximity ranking, typo automata for bounded-edit-distance fuzzy matching, and optional ML sections for query parsing and candidate ranking. The engine touches only the pages a query needs, which is why lookups stay in the millisecond range even on modest hardware.

Country-specific behavior lives in the data, not the binary. Normalization and parsing rule tables ship inside the sheet itself as a dedicated section, so a monthly data release can fix a country's quirks — abbreviations, renamed streets, administrative reshuffles — without an engine upgrade; engine and data are versioned independently. This repository contains the public parts: the Rust engine and CLI, the Python bindings, the DuckDB extension, the data pipeline (DuckDB SQL under prep/), and the docs. The rule tables (shipped inside paid data files), the evaluation corpora, and the ML training code are private.

Verifying a release

Every release is covered by one signed attestation. The signature spans the asset graph — the sheets, the binaries and this checker, each by size and two hashes. It does not cover SHA256SUMS itself: that file lists the proofs, so it cannot be inside them. The checksums are still pinned, because every line in them must match the signed graph — but the authority is the attestation, not the checksum file. Two properties make the check worth anything, and both are about order and source, not about running more commands.

The trust root never comes from the channel it checks. gridpin-release-signers (the public half of the signing key) and verify_release.py come from the GitHub release; the data files and the proofs come from dl.gridpin.dev. Whoever controls one channel cannot hand you both a forged file and the key that blesses it.

Nothing you downloaded runs until it has been authenticated. verify_release.py is an ordinary Python program: running it first and checking signatures afterwards would mean executing an untrusted download. Steps 3–5 below use only ssh-keygen and shasum, which you already trust, and only step 6 runs our code.

mkdir gridpin-v0.4.0 && cd gridpin-v0.4.0
mkdir trust data          # two directories on purpose: the checker never sits in what it checks
gh_base=https://github.com/gridpin/gridpin/releases/download/v0.4.0

# 1. TRUST ROOT — from GitHub, never from the download host
curl -fsSL -o trust/gridpin-release-signers "$gh_base/gridpin-release-signers"
curl -fsSL -o trust/verify_release.py       "$gh_base/verify_release.py"

# 2. Data and proofs — from the download host
for f in france.bin germany.bin italy.bin netherlands.bin serbia.bin fr_poi.bin spain.bin brazil.bin \
         SHA256SUMS attestation.json attestation.json.sig; do
  curl -fsSL -o "data/$f" "https://dl.gridpin.dev/v0.4.0/$f"
done

# 3. The key is the one published below — compare by eye, before anything else
ssh-keygen -lf trust/gridpin-release-signers
#    expected: SHA256:Y1Q/c9oMgST5VkyU78Py/XM5QiQP8KXwe0fopZA+YXA

# 4. The attestation really is signed by that key (system ssh-keygen, not our code)
ssh-keygen -Y verify -f trust/gridpin-release-signers -I gridpin-release \
           -n gridpin-g02 -s data/attestation.json.sig < data/attestation.json \
  || { echo "signature does not verify — STOP"; exit 1; }

# 5. The checker you downloaded is the one that signature covers.
#    Its expected hash comes out of the attestation you just authenticated.
want=$(python3 -c 'import json;print([a["sha256"] for a in json.load(open("data/attestation.json"))["assets"] if a["name"]=="verify_release.py"][0])')
test "$want" = "$(shasum -a 256 trust/verify_release.py | cut -d" " -f1)" \
  || { echo "checker does not match the signed attestation — STOP"; exit 1; }

# 6. Only now run it, from outside the directory it judges.
python3 trust/verify_release.py --dir data --channel r2 \
        --allowed-signers trust/gridpin-release-signers \
        --expected-public-sha <commit from release notes>

Expected output: OK: owner signature verified; N assets, checksums and attestation agree. Any other exit code means do not use the files.

Step 3 is the one thing a machine cannot do for you. The published fingerprint is

SHA256:Y1Q/c9oMgST5VkyU78Py/XM5QiQP8KXwe0fopZA+YXA

If it ever differs and no signed announcement explains the change, stop and write to contact@gridpin.dev.

Data licensing & attribution

The engine is Apache-2.0. Each sheet carries the license of its source data:

• France — BAN, under Licence Ouverte 2.0.
• Italy — ANNCSU via Overture/OpenAddresses, under CC BY 4.0.
• Netherlands — Nationaal Georegister (BAG) via Overture, under Public Domain Mark 1.0.
• Serbia — RGZ via Overture, under data.gov.rs Terms of use; settlement-name aliases from GeoNames (CC BY 4.0).
• POI layer — Overture places, mixed permissive: CDLA-Permissive-2.0 (Meta, Microsoft, …), Apache-2.0 (Foursquare), CC0-1.0 (AllThePlaces).

Per the Overture attribution page, addresses are not one blanket license — each national source carries its own. Consult your own counsel before commercial redistribution.

All of these licenses let you store geocoding results indefinitely. This is a real difference from hosted APIs: Google's terms forbid storing results and allow caching coordinates for at most 30 days, and Mapbox charges roughly 7.5× for permanent storage — at list prices of about $3,550 (Google) to $4,500 (Mapbox) per million requests per month before you even ask to keep the output (List prices as of 2026-08, 1M requests/month; see the linked provider terms). With GridPin the computation happens on your hardware, so the results are yours from the start. The grid is ours. The pin is yours.

This also matters for GDPR: the addresses you geocode are often customer data, and with GridPin they never leave your infrastructure.

Status & roadmap

v0.4.0: Brazil added. Client update required. Brazil is one nationwide sheet covering 26 states and the Federal District; the source counts describe source presence, not address completeness. Spain covers all 52 postal provinces (incl. Ceuta and Melilla). Germany covers 15 of 16 Länder; Bavaria is not covered. Use the 0.4.0 client with this release: older engines do not contain the Brazilian rules. All seven country sheets and the France POI layer use the new immutable v0.4.0/ path and a new attestation; v0.1.0/, v0.2.0/ and v0.3.0/ are unchanged.

For an existing Python installation, use pip install --upgrade gridpin==0.4.0, not a plain install that may keep an older version.

Interfaces and file formats may still change before v1.0. Sheets are tied to the engine's format major version — keep the engine build that shipped alongside your sheets; before v1.0 a newer engine may require newer sheets.

Planned distribution:

• Free — static builds of all available countries, with no update schedule. Free builds carry the same curated rules section subscribers get — you trade freshness, not quality; fresh monthly sheets are what subscriptions are for.
• Starter, $59/mo — a subscription: one country of your choice, a fresh sheet every month.
• Pro, $149/mo — a subscription: the full atlas (all available countries), fresh sheets monthly, provenance journal per build, invoice billing, priority email support.
• Snapshot, $199 one-time — this month's fresh build of all available countries (the same sheets subscribers get), with an invoice, without a subscription. No updates afterwards. It costs more than one month of Pro on purpose: it is the no-subscription option — one invoice for procurement, no card on file, nothing to cancel. If a subscription works for you, a month of Pro is cheaper.
• OEM / embedding — from $1,500/yr.

Prices above describe what is planned; they are not binding and nothing is on sale yet.

License

The code in this repository is licensed under Apache-2.0. Data files are licensed separately by source — see Data licensing & attribution.
