A Model Context Protocol server for the Xahau network with two firsts: it runs a Hook's real WebAssembly bytecode in a local VM (no xahaud node required), and it runs a Hooks-specific static-analysis / security rule engine over it — both fully offline. Around that core it adds read-only ledger access, a Xahau-aware binary codec, an instruction-count fee estimate, network-reward math, governance helpers, and unsigned-transaction builders.

Xahau is the XRPL fork whose flagship feature is Hooks — small on-ledger WebAssembly smart contracts. There was no MCP for Xahau and no static analyzer for Hooks; this is both.

Why it's useful

Point any MCP-capable agent (Claude, etc.) at this server and it can:

• Run a Hook without deploying it — execute_hook instantiates the real CreateCode WASM in a local VM, supplies the Hook API over a simulated transaction + ledger state, and reports the actual accept/rollback decision, return code/string, state writes, emitted transactions and a call trace. The first dev-accessible Hook simulator that needs no xahaud node.
• Audit a Hook before it's installed — paste the CreateCode WASM (or an on-ledger hook hash) and get SARIF-lite findings: missing accept/rollback exit, unguarded loops (_g), unknown env imports, dangerous HookGrants, over-broad HookOn, and more.
• Decode the cryptic HookOn bitmap in both directions — the 256-bit, inverted, active-low mask (with the active-high SetHook bit) is easy to get wrong; here it's verified and round-trip-tested.
• Read Xahau ledger state — accounts, installed hooks, hook definitions, hook state, transactions (with HookExecutions metadata), ledgers.
• Build unsigned transactions (SetHook, ClaimReward, Payment) with an automatic security preflight — returned unsigned, to be signed offline.

Safety posture

• Read-only toward the network. There is no submit and no sign anywhere in this server.

• No key custody. Builder tools never accept a secret/seed and always return an unsigned transaction plus instructions to sign offline (e.g. with xaman or xrpl-accountlib). They default to testnet.

• Honest fidelity. execute_hook runs the real bytecode against a simulated environment. The VM implements a large slice of the 78-function Hook API — the full XFL float API (verified against float_one), the slot table + STObject subfield extraction (slot_subfield/sto_subfield, byte-exact against real txns), state, otxn_*/hook_*, util_accid/util_raddr/util_verify/util_sha512h, and more. STObject mutation (sto_emplace/erase/validate), util_keylet (account + hook verified against live ledger indexes; offer/escrow/check/ticket/signers canonical + fail-safe), and slot_set with async pre-resolve (execute_hook resolveKeylets:true fetches the ledger objects the hook reads and re-runs) are now supported. What still can't be faithful is honestly recorded: unverified keylet subtypes, meta_slot, and other un-modelled calls return the real NOT_IMPLEMENTED code, are listed in unsupportedCalls, and mark the run degraded — never faked. The VM models the guard budget (_g enforces each guard's declared maxiter → GUARD_VIOLATION), and reports stateApplied (state writes commit only on accept, discarded on rollback). It is not a consensus-faithful xahaud replica — it has no fee/fuel metering beyond guards, XFL math truncates rather than round-half-up (so float_mulratio's round-up flag and last-significant-digit results can differ), value-level math is verified only where tested. Hooks with a loop but no _g guard are refused before execution (invalid on-chain), and guarded runs are bounded by a VM budget (1M cumulative guard calls / 2s wall clock — labeled as a local VM cap, not a consensus limit); always confirm financial/resource hooks on testnet. hook_dry_run is STATIC_ONLY, compute_reward is DOCUMENTED_MODEL, estimate_hook_fee is ESTIMATE.

• Resources & prompts. Beyond tools, the server exposes MCP resources (xahau://rules, xahau://hook-api, xahau://tx-types) and guided prompts (audit_hook, simulate_hook, explain_hook) so agents can pull reference data and run the common workflows directly.

Tools

Hook intelligence (offline — the core)

Codec / decode (offline)

Ledger (read-only RPC)

Economics / governance

Unsigned builders (no keys, testnet-default)

Install

New here or non-technical? Start with the plain-English tutorial — what it does + cool things to just ask.

Install straight from GitHub — no npm-registry account needed; it builds on install:

npm install -g github:Hugegreencandle/xahau-mcp

Or clone and build:

git clone https://github.com/Hugegreencandle/xahau-mcp && cd xahau-mcp
npm install        # the `prepare` script compiles dist/ automatically
npm run smoke      # health check + a live mainnet read
npm test           # ~115 tests (offline)

Also published to GitHub Packages as @hugegreencandle/xahau-mcp. GitHub Packages requires auth even for public installs, so add to your .npmrc:

@hugegreencandle:registry=https://npm.pkg.github.com
//npm.pkg.github.com/:_authToken=YOUR_GITHUB_TOKEN   # token with read:packages

then npm install -g @hugegreencandle/xahau-mcp. (The github: install above needs no auth and is simpler.)

Add to an MCP client (e.g. Claude Code / Desktop):

{ "mcpServers": { "xahau": { "command": "xahau-mcp" } } }

Security

Designed defensively and reviewed (npm audit + a danger-surface pass):

• Read-only & no key custody — no sign/submit anywhere; builder tools never accept a secret and only emit unsigned transactions to sign offline.
• No code-exec surface — no eval/Function, no child_process/shell, no filesystem writes, no dynamic require. RPC fetch only ever hits the fixed endpoints in data/endpoints.json (or your XAHAU_RPC_URLS override) — never a URL built from tool input, so no SSRF.
• Untrusted Hook WASM is sandboxed — execute_hook/fuzz_hook run hook bytecode in Node's WebAssembly engine, which has no syscall/fs/network access; a hook can only call the in-memory JS Hook-API shims, with bounds-checked memory reads/writes.
• Known limits (DoS-of-self, not RCE/exfil): the VM has no fuel metering beyond guards, so a pathological unguarded infinite-loop hook can hang a single run — just cancel it. Tool output is data, not instructions (treat it as such, as with any MCP).
• Dependencies: npm audit reports only low-severity advisories transitively under xrpl-accountlib's signing libraries (elliptic/bip32/tiny-secp256k1) — code paths this server never calls (it uses only the binary codec).

How it works

• No heavy deps. Three runtime deps: @modelcontextprotocol/sdk, zod, and xrpl-accountlib (used only for the Xahau-aware binary codec; its signing surface is never called). RPC is plain fetch; the WASM reader is hand-rolled and zero-dep; the VM uses Node's built-in WebAssembly engine to run the bytecode with a JS Hook API shim — no WASM toolchain or native deps.
• Real data, regenerable. data/ is built from a live Xahau node's server_definitions and the canonical Hook API list (Xahau/hooks-rs c/extern.h) via npm run fetch:all. The 78-function Hook API catalog carries per-function hazard metadata that drives the analyzer.
• HookOn semantics are verified against the Xahau docs: 256-bit, bit n = tx type n, inverted/active-low (set = does not fire), with bit 22 (SetHook) active-high.

License

MIT © 2026 Dane Brown. Not affiliated with XRPL Labs or the Xahau project. Analyzer findings are heuristic guidance, not a security guarantee — always test on testnet and review hooks independently before mainnet use.
