Aseprite Live MCP Server

aseprite-live-mcp

Let an AI agent draw in your live Aseprite editor — one named undo per edit — with a Unity-first, game-dev toolset.

An open-source Model Context Protocol server for Aseprite. It drives your running editor (all open documents, unsaved state, each edit a single Ctrl-Z) and runs headless (aseprite --batch) against files on disk — 77 typed tools from one server, including one-action Unity sprite-sheet + .meta export (named slices carry per-slice pivots), a project-convention art-QA sweep, and isometric drawing primitives we haven't found in another Aseprite MCP. It also exposes MCP prompts — guided one-call art workflows we haven't seen another Aseprite MCP ship — and MCP resources that read your live editor's open documents, active palette, and last QA/export report (a live-state resource set unique to the live bridge).

See it in action

Each of these is an AI agent driving a live 64×64 Aseprite canvas through the MCP — one named undo per step.

Install

Recommended — one command (no clone):

uvx aseprite-live-mcp        # or: pipx run aseprite-live-mcp

From source:

git clone https://github.com/oaktreegames/aseprite-live-mcp
cd aseprite-live-mcp
pip install -e .

Requires Python 3.10+ and Aseprite 1.3+. That's it for headless; the live editor needs one extra step (below).

Quickstart — headless (2 minutes, no editor open)

Add the server to your MCP client (Claude Code, Claude Desktop, Cursor, …):

{
  "mcpServers": {
    "aseprite-live": {
      "command": "uvx",
      "args": ["aseprite-live-mcp"],
      "env": {
        "ASEPRITE_MCP_BACKEND": "headless",
        "ASEPRITE_PATH": "C:/Program Files/Aseprite/Aseprite.exe"
      }
    }
  }
}

Set ASEPRITE_PATH to your Aseprite executable (auto-detected on common installs if you omit it). In headless mode, tools take a file argument — the .aseprite to act on. Ask your agent to run status to confirm the connection.

Quickstart — live editor (drive your open canvas)

The live backend edits your running Aseprite, one undo step per edit.

1. Install the bridge script into Aseprite — in Aseprite, File → Scripts → Open Scripts Folder, and copy aseprite_client/claude-bridge.lua into it. Restart Aseprite (or File → Scripts → Rescan Scripts Folder).
2. Start the relay: python bridge/relay_server.py (needs pip install websockets).
3. Connect: in Aseprite, File → Scripts → claude-bridge, and grant the script trust when asked. The panel shows "connected to Claude", live activity, and a Pause toggle.
4. Switch the backend to live in your MCP config ("ASEPRITE_MCP_BACKEND": "live").

Now tools act on your active document; watch edits appear and press Ctrl-Z to undo each one. See docs/ARCHITECTURE.md for how it works.

What you can ask it to do

• "Make a 32×32 sprite, draw a red circle, and export it as icon.png."
• "Measure the transparent padding on player.aseprite and tell me if it's centered."
• "Export machines.aseprite as a Unity sprite sheet at 16 pixels-per-unit." → drops a sheet + a pre-sliced .meta straight into your Unity project.
• "Draw an isometric box for a 1×1 machine base and put a recessed port on its front face."
• "Run a QA sweep on this sprite: it must be 64×64, ≤ 16 colors, and grid-aligned."
• "Pull a 16-color palette out of concept.png and snap my sprite to it."
• "Slice this atlas, set each slice's pivot, and export it to Unity with the pivots baked in."

Sanity check the whole surface: python tests/smoke_headless.py exercises all 77 tools (plus resources + prompts) end-to-end against a throwaway sprite (pip install -e ".[dev]" then pytest for the unit + headless suite).

Where this sits (honest positioning)

There are already good Aseprite MCP servers. This project is not the first, and doesn't claim to be. What it claims — and can defend:

We don't compete on raw tool count (the leaders ship 100+). The pitch is curated, Unity-first, and QA-gated, with an MCP-native integration layer — guided-workflow prompts (which we haven't seen another Aseprite MCP ship) and live-state resources (unique to the live bridge).

Tools (77)

• Inspect — status, get_sprite_info, get_pixel, get_pixels (composited read-back for the AI feedback loop), get_color_stats (histogram)
• Canvas / layers / frames / cels — create_sprite; add_layer/delete_layer/rename_layer/set_layer_visibility/set_layer_opacity/set_layer_blend_mode/duplicate_layer/merge_layer_down/move_layer/import_image_as_layer/flatten_sprite; add_frame/duplicate_frame/delete_frame/set_frame_duration; clear_cel/set_cel_position/set_cel_opacity
• Tags — create_tag, list_tags, delete_tag
• Draw — draw_rectangle, draw_line, draw_circle, draw_ellipse, draw_gradient (optional dither), apply_dither (ordered Bayer), add_outline, fill_area
• Palette / color — get_palette, set_palette_color, add_palette_color, set_palette, apply_preset_palette (gameboy/pico8/cga), generate_color_ramp (hue-shifted), extract_palette_from_image (median-cut); replace_color, quantize_to_palette, adjust_hsl
• Shading — apply_shading, palette_ramp_walk (index-adjacency ramp shading)
• Selection / transform — select_rectangle/select_all/deselect; flip_sprite/rotate_sprite/resize_sprite/crop_sprite
• Slices — create_slice, set_slice_pivot, set_slice_center (9-patch), list_slices, delete_slice
• Animation — tween_frames, smear_frame
• Isometric — draw_iso_box, draw_iso_cylinder, fill_polygon, iso_recessed_panel (2:1 iso primitives with automatic top/left/right face shading)
• Export — export_sprite (honest multi-frame split reporting), export_spritesheet (+ JSON atlas), export_unity_sprite (frames), export_unity_slices (named slices, per-slice pivots)
• Batch (whole folder, headless, non-destructive) — batch_export, batch_resize, batch_apply_palette
• Editor — undo, redo · Advanced — run_lua (guarded escape hatch)
• Art-QA — measure_padding, qa_sweep

Every tool is typed with accurate MCP annotations (readOnlyHint / destructiveHint / idempotentHint / openWorldHint); mutating tools are wrapped in a named app.transaction, so each edit is exactly one undo step (the editor shows "Undo "). The QA and Unity-export tools also declare an outputSchema and return structuredContent. Built on the official MCP Python SDK's FastMCP, stdio transport, targeting the stable 2025-11-25 spec.

Resources

Read live editor state without spending a tool call — enabled by the live bridge:

• aseprite://sprite/active — size, color mode, layer/frame/tag names of the active document
• aseprite://palette/active — the active palette as hex
• aseprite://docs — every open document, including unsaved/untitled tabs
• aseprite://qa/last — the most recent qa_sweep / measure_padding result
• aseprite://export/last — the most recent Unity export (files written + sprite manifest)

Prompts (guided workflows)

One-call "skills" that chain the tools into finished art tasks:

• unity_qa_gate — run the ship-ready QA gate, then export a Unity sheet + .meta
• iso_building_to_spec — build a 2:1 isometric building from a footprint spec
• shade_along_ramp — shade a sprite by walking its hand-ordered palette ramp
• autoslice_to_unity — multi-frame sprite → Unity-import-ready sheet + pre-sliced .meta
• concept_to_placeholder — external concept image → correctly-padded, in-palette placeholder

Security

The relay executes Lua inside Aseprite — treat it as local code execution. It binds to 127.0.0.1 only, and every edit is one undo step. Full threat model: SECURITY.md.

Contributing

Issues and PRs welcome — see CONTRIBUTING.md. Run pytest and python tests/smoke_headless.py before submitting.

License

MIT — see LICENSE. © 2026 Kyle Ocheltree / OakTree Games.
