Contextweaver MCP Server

ContextWeaver

---

ContextWeaver is a semantic retrieval engine purpose-built for AI coding assistants. It combines hybrid search (vector + lexical), intelligent context expansion, and token-aware packing to deliver precise, relevant, and context-complete code snippets to LLMs.

✨ Core Features

🔍 Hybrid Retrieval Engine

• Vector Retrieval: deep semantic understanding via similarity
• Lexical Retrieval (FTS): exact matching for function names, class names, and other technical terms
• RRF Fusion (Reciprocal Rank Fusion): intelligently merges multiple recall channels

🧠 AST Semantic Chunking

• Tree-sitter parsing: supports TypeScript, JavaScript, Python, Go, Java, Rust, C, C++, C#, and more
• Dual-Text strategy: displayCode for presentation, vectorText for embedding
• Gap-Aware merging: handles code gaps intelligently while preserving semantic integrity
• Breadcrumb injection: vector text carries hierarchical paths to boost recall
• UTF-16 character-domain normalization: offsets are unified via SourceAdapter.toCharOffset before writing metadata, preventing multi-byte character slicing errors (v1.4.0+)

📊 Three-Stage Context Expansion

• E1 Neighbor expansion: adjacent chunks within the same file, preserving block completeness
• E2 Breadcrumb completion: sibling methods under the same class/function for structural understanding
• E3 Import resolution: cross-file dependency tracking (configurable toggle)

🎯 Smart TopK Cutoff

• Anchor & Floor: dynamic threshold plus an absolute floor as dual safeguards
• Delta Guard: prevents misjudgment in Top1-outlier scenarios
• Safe Harbor: the first N results only check the floor, guaranteeing baseline recall

🔌 Native MCP Support

• MCP Server mode: launch a Model Context Protocol server with one command
• Multi-tool granularity (v1.5.0+): beyond core semantic retrieval, adds dedicated tools for structure browsing, symbol references, symbol definitions, and statistics
• Intent/term separation: an LLM-friendly API design
• Auto-indexing: the first query triggers indexing automatically; incremental updates are transparent

⚡ Query Cache & File Watching (v1.5.0+)

• Query cache (QueryCache): in-process per-project LRU cache (50 entries by default); a hit skips the entire vector recall / rerank / expansion pipeline
• Automatic cache invalidation: the cache key is composed of normalized query + projectId + index version + search-config fingerprint, so it invalidates automatically after an index update or config change — stale results are never returned
• Watch mode: contextweaver watch watches the filesystem and triggers incremental indexing automatically, with debouncing (500ms by default) and scan de-duplication (no concurrent scans)

📈 Statistics & Observability (v1.5.0+)

• Three metric groups: indexing process, search quality/behavior, health/consistency
• Dual exits: contextweaver stats CLI (with --json) plus the MCP stats tool
• Consistency diagnostics: automatically detects abnormal migration state, pending_marks backlog, missing vector rows, and more — with suggested fixes

🛡️ Crash-Safe Data Architecture (v1.4.0+)

• Single source of truth for content: LanceDB stores only vectors and locating metadata; content is read back from files.content, reducing index size by 30–50%
• Cross-store transactional compensation: three-stage write LanceDB → FTS+outbox → SQLite mark, with automatic rollback or replay on any failure
• Migration state machine: pending/done/aborted persisted, auto-rebuilt on crash recovery
• Cross-process mutual exclusion: an advisory lock prevents the MCP server and CLI from triggering LanceDB migration concurrently
• chunk_id de-duplication: pre-delete before write to avoid duplicate rows on retry

📦 Quick Start

Requirements

• Node.js >= 20
• pnpm (recommended) or npm

Installation

# Global install
npm install -g @chiway/contextweaver

# Or with pnpm
pnpm add -g @chiway/contextweaver

Initialize Configuration

# Create the config file (~/.contextweaver/.env)
contextweaver init
# Or the short alias
cw init

Edit ~/.contextweaver/.env and fill in your API keys:

# Embedding API config (required)
EMBEDDINGS_API_KEY=your-api-key-here
EMBEDDINGS_BASE_URL=https://api.siliconflow.cn/v1/embeddings
EMBEDDINGS_MODEL=BAAI/bge-m3
EMBEDDINGS_MAX_CONCURRENCY=10
EMBEDDINGS_DIMENSIONS=1024

# Reranker config (required)
RERANK_API_KEY=your-api-key-here
RERANK_BASE_URL=https://api.siliconflow.cn/v1/rerank
RERANK_MODEL=BAAI/bge-reranker-v2-m3
RERANK_TOP_N=20

# Search parameters (optional, override built-in defaults)
CW_SEARCH_WVEC=0.6
CW_SEARCH_WLEX=0.4
CW_SEARCH_RERANK_TOP_N=10
CW_SEARCH_MAX_TOTAL_CHARS=48000
CW_SEARCH_VECTOR_TOP_K=80
CW_SEARCH_SMART_MAX_K=8
CW_SEARCH_IMPORT_FILES_PER_SEED=3

# Ignore patterns (optional, comma-separated)
# IGNORE_PATTERNS=.venv,node_modules

Index a Codebase

# Run from the codebase root
contextweaver index

# Specify a path
contextweaver index /path/to/your/project

# Force a full re-index
contextweaver index --force

Watch Mode (v1.5.0+)

# Watch for file changes and auto-index incrementally (Ctrl+C to stop)
contextweaver watch

# Specify a path and debounce window (ms)
contextweaver watch /path/to/project --debounce 800

watch runs one full incremental scan on startup, then listens to filesystem events; changes trigger a de-duplicated scan within the debounce window, and paths excluded by ignore rules never trigger a scan.

Local Search

# Semantic search
cw search --information-request "How is the user authentication flow implemented?"

# With exact terms
cw search --information-request "Database connection logic" --technical-terms "DatabasePool,Connection"

Structure Browsing & Symbol Lookup (v1.5.0+)

The following commands are CLI mirrors of MCP tools, with zero Embedding API cost:

# List indexed files (supports glob / language / count filters)
contextweaver list-files --glob "src/**/*.ts" --language typescript --max-results 100

# Look up a symbol definition
contextweaver definition SearchService --hint-path src/search

# Look up symbol references
contextweaver references handleStats --exclude-definition

Statistics (v1.5.0+)

# Human-readable stats report
contextweaver stats

# JSON output (for scripting)
contextweaver stats --json

# Specify a project path
contextweaver stats --path /path/to/project

Start the MCP Server

# Launch the MCP server (for use by Claude and other AI assistants)
contextweaver mcp

Index Management (v1.4.0+)

# Show LanceDB migration state
contextweaver migrate

# Clear the aborted state: wipe LanceDB and trigger a full rebuild
# Triggered when: the Indexer refuses to write after sampling validation fails;
# run this, then index again.
contextweaver migrate --reset

# Specify a project path
contextweaver migrate --path /path/to/project

🔧 MCP Integration

Claude Desktop Configuration

Add the following to your Claude Desktop config file:

{
  "mcpServers": {
    "contextweaver": {
      "command": "contextweaver",
      "args": ["mcp"]
    }
  }
}

MCP Tools Overview (v1.5.0+)

ContextWeaver exposes 5 MCP tools, following a layered design of "semantic retrieval first, structure browsing second":

codebase-retrieval Parameters

list-files Parameters

find-references Parameters

get-symbol-definition Parameters

Note: find-references and get-symbol-definition are heuristic text lookups over indexed chunks, not compiler-accurate navigation. For exhaustive raw text matching, use grep outside MCP.

Design Philosophy

• Intent/term separation: information_request describes "what to do", technical_terms filters "what it's called"
• Same-file context first: same-file context is provided by default; cross-file exploration is initiated by the agent
• Return to agent instincts: the tool only locates; cross-file exploration is triggered by the agent on demand

🏗️ Architecture

flowchart TB
    subgraph Interface["CLI / MCP Interface"]
        CLI[contextweaver CLI]
        MCP[MCP Server]
    end

    subgraph Search["SearchService"]
        QC[QueryCache<br/>LRU]
        VR[Vector Retrieval]
        LR[Lexical Retrieval]
        RRF[RRF Fusion + Rerank]
        QC -.cache hit.-> CP
        VR --> RRF
        LR --> RRF
    end

    subgraph Expand["Context Expansion"]
        GE[GraphExpander]
        CP[ContextPacker]
        GE --> CP
    end

    subgraph Storage["Storage Layer"]
        VS[(VectorStore<br/>LanceDB)]
        DB[(SQLite<br/>FTS5)]
    end

    subgraph Index["Indexing Pipeline"]
        CR[Crawler<br/>fdir] --> SS[SemanticSplitter<br/>Tree-sitter] --> IX[Indexer<br/>Batch Embedding]
    end

    Interface --> Search
    RRF --> GE
    Search <--> Storage
    Expand <--> Storage
    Index --> Storage

Core Modules

Data Architecture (v1.4.0+)

~/.contextweaver/<projectId>/
├── index.db                 # SQLite
│   ├── files                # File metadata + full content (content column, the only source for text slicing)
│   ├── files_fts            # External-content table, inverted index pointing to files
│   ├── chunks_fts           # Chunk-level inverted index, per-file wholesale replacement
│   ├── metadata             # schema_version / lancedb_migration_state / lock
│   ├── stats                # Cumulative index/search counters (v1.5.0+)
│   └── pending_marks        # Outbox: replayed when a vector_index_hash mark failed
└── vectors.lance/           # LanceDB chunks table (vectors + locating metadata only, no content)

Key invariants:

• The single source of truth for content is files.content; ChunkContentLoader slices via start_index/end_index (same source as displayCode)
• All LanceDB offset fields live in the UTF-16 character domain; multi-byte files are never sliced incorrectly
• Cross-store write order: LanceDB → (FTS + outbox single transaction) → SQLite mark + clear outbox
• LanceDB migration state pending/done/aborted is persisted, with cross-process mutual exclusion via an advisory lock
• The query cache key is bound to the index version and search-config fingerprint; it invalidates on any index or config change

📁 Project Structure

contextweaver/
├── src/
│   ├── index.ts              # CLI entry (init / index / watch / search / mcp / migrate / stats)
│   ├── config.ts             # Config management (environment variables)
│   ├── defaultEnv.ts         # Default .env template
│   ├── cli/
│   │   └── mirrorCommands.ts # CLI mirrors of MCP tools (list-files / definition / references)
│   ├── api/                  # External API wrappers
│   │   ├── embedding.ts      # Embedding API
│   │   └── reranker.ts       # Reranker API
│   ├── chunking/             # Semantic chunking
│   │   ├── SemanticSplitter.ts   # AST semantic chunker
│   │   ├── SourceAdapter.ts      # Source adapter (UTF-16/UTF-8 domain normalization)
│   │   ├── LanguageSpec.ts       # Language spec definitions
│   │   ├── ParserPool.ts         # Tree-sitter parser pool
│   │   └── types.ts              # Chunking type definitions
│   ├── scanner/              # File scanning
│   │   ├── index.ts          # Scan orchestration
│   │   ├── crawler.ts        # Filesystem traversal
│   │   ├── processor.ts      # File processing
│   │   ├── watcher.ts        # File-watch coordinator (v1.5.0+)
│   │   ├── filter.ts         # Filter rules
│   │   ├── hash.ts           # File hash
│   │   └── language.ts       # Language detection
│   ├── indexer/              # Indexer
│   │   └── index.ts          # Three-stage transaction (LanceDB → FTS+outbox → SQLite mark)
│   ├── vectorStore/          # Vector storage
│   │   └── index.ts          # LanceDB adapter (pure vector operations)
│   ├── db/                   # Database
│   │   ├── index.ts          # SQLite + FTS5 + pending_marks + migration state machine + stats counters
│   │   └── bootstrap.ts      # Cross-store init coordinator (v1.4.0+)
│   ├── search/               # Search service
│   │   ├── SearchService.ts      # Core search service (cache-integrated)
│   │   ├── QueryCache.ts         # Per-project LRU query cache (v1.5.0+)
│   │   ├── GraphExpander.ts      # Context expander
│   │   ├── ContextPacker.ts      # Context packer
│   │   ├── ChunkContentLoader.ts # Slices by (path, start_index, end_index) (v1.4.0+)
│   │   ├── fts.ts                # Full-text search (per-file wholesale replacement)
│   │   ├── config.ts             # Search default config + value bounds
│   │   ├── loadConfig.ts         # Env-var overrides + config fingerprint (v1.5.0+)
│   │   ├── types.ts              # Type definitions
│   │   ├── utils.ts              # Token-overlap scoring
│   │   └── resolvers/            # Multi-language import resolvers
│   │       ├── JsTsResolver.ts
│   │       ├── PythonResolver.ts
│   │       ├── GoResolver.ts
│   │       ├── JavaResolver.ts
│   │       ├── RustResolver.ts
│   │       ├── CppResolver.ts
│   │       └── CSharpResolver.ts
│   ├── stats/                # Statistics aggregation layer (v1.5.0+)
│   │   └── index.ts          # Aggregates and renders index/search/health metrics
│   ├── mcp/                  # MCP server
│   │   ├── server.ts         # MCP server implementation (registers 5 tools)
│   │   ├── main.ts           # MCP entry
│   │   └── tools/
│   │       ├── index.ts                 # Tool registry
│   │       ├── shared.ts                # Shared tool logic
│   │       ├── codebaseRetrieval.ts     # Code retrieval tool
│   │       ├── listFiles.ts             # File structure browsing (v1.5.0+)
│   │       ├── findReferences.ts        # Symbol reference lookup (v1.5.0+)
│   │       ├── getSymbolDefinition.ts   # Symbol definition lookup (v1.5.0+)
│   │       └── stats.ts                 # Statistics tool (v1.5.0+)
│   └── utils/                # Utilities
│       ├── logger.ts         # Logging system
│       ├── encoding.ts       # Encoding detection
│       └── lock.ts           # File lock
├── tests/                    # Unit + integration tests (28 test files, 156 test cases)
│   ├── chunking/             # SourceAdapter / chunking
│   ├── cli/                  # mirrorCommands
│   ├── db/                   # migration, outbox, advisory lock, index-version
│   ├── indexer/              # transaction compensation, GC, aborted guard
│   ├── integration/          # real LanceDB end-to-end
│   ├── mcp/                  # list-files / find-references / get-symbol-definition / shared / tool registry
│   ├── scanner/              # watcher / index-version
│   ├── search/               # FTS, ChunkContentLoader, Packer, cache, loadConfig
│   ├── stats/                # statistics aggregation
│   └── vectorStore/          # chunk_id de-duplication, sampling validation
├── package.json
└── tsconfig.json

⚙️ Configuration Reference

Environment Variables

Search Parameter Env Overrides (v1.5.0+)

The following environment variables override built-in defaults; out-of-range values are automatically clamped to the valid interval. When only one of wVec/wLex is set, the other is automatically set to 1 - x.

Search Config Parameters (built-in defaults)

interface SearchConfig {
  // === Recall ===
  vectorTopK: number;        // Vector recall candidates (default 80)
  vectorTopM: number;        // Vectors kept after dedup (default 60)
  ftsTopKFiles: number;      // FTS recall file count (default 20)
  lexChunksPerFile: number;  // Lexical chunks per file (default 2)
  lexTotalChunks: number;    // Total lexical chunks (default 40)

  // === Fusion ===
  rrfK0: number;             // RRF smoothing constant (default 20)
  wVec: number;              // Vector weight (default 0.6)
  wLex: number;              // Lexical weight (default 0.4)
  fusedTopM: number;         // Candidates fed into rerank after fusion (default 60)

  // === Rerank ===
  rerankTopN: number;        // Results kept after rerank (default 10)
  maxRerankChars: number;    // Max chars per chunk sent to reranker (default 1000)
  maxBreadcrumbChars: number;// Max chars for breadcrumb context (default 250)
  headRatio: number;         // Head/tail ratio when truncating (default 0.67)

  // === Expansion ===
  neighborHops: number;      // E1 neighbor hops (default 2)
  breadcrumbExpandLimit: number;  // E2 breadcrumb completions (default 3)
  importFilesPerSeed: number;     // E3 import files per seed (default 3)
  chunksPerImportFile: number;    // E3 chunks per import file (default 3)

  // === ContextPacker ===
  maxSegmentsPerFile: number;     // Max non-contiguous segments per file (default 3)
  maxTotalChars: number;          // Token budget (chars, default 48000)

  // === Smart TopK ===
  enableSmartTopK: boolean;       // Enable smart cutoff (default true)
  smartTopScoreRatio: number;     // Dynamic threshold ratio (default 0.5)
  smartTopScoreDeltaAbs: number;  // Max absolute drop from Top1 (default 0.25)
  smartMinScore: number;          // Absolute floor (default 0.25)
  smartMinK: number;              // Safe Harbor count (default 2)
  smartMaxK: number;              // Hard upper bound (default 8)
}

🌍 Multi-Language Support

ContextWeaver natively supports AST parsing for the following languages via Tree-sitter:

Other languages fall back to line-based chunking and can still be indexed and searched normally.

🔄 Workflows

Indexing Flow

0. Bootstrap   → pending_marks replay + LanceDB schema migration (first launch)
1. Crawler     → traverse the filesystem, filter ignored items
2. Processor   → read file content, compute hash
3. Splitter    → AST parse, semantic chunking (offsets normalized to UTF-16 char domain)
4. Indexer     → batch embedding
5. Stages 4-6 pseudo-transaction:
   ├─ LanceDB write (pre-delete (path, hash) to avoid duplicates → add → clear old versions)
   ├─ FTS + outbox single SQLite transaction (rolls back LanceDB on failure)
   └─ SQLite mark + clear outbox single transaction (outbox kept on failure, replayed next launch)
6. Trailing GC → clean up LanceDB orphan chunks (time budget 5s)

Search Flow

1. Query Parse     → parse the query, separate semantics from terms
2. Cache Lookup    → return immediately on hit (v1.5.0+, key includes index version + config fingerprint)
3. Hybrid Recall   → dual-channel vector + lexical recall
4. RRF Fusion      → Reciprocal Rank Fusion
5. Rerank          → cross-encoder reranking
6. Smart Cutoff    → intelligent score cutoff
7. Graph Expand    → neighbor/breadcrumb/import expansion
8. Context Pack    → segment merging, token budget
9. Cache Store     → write to cache (v1.5.0+)
10. Format Output  → format and return to the LLM

📊 Performance Characteristics

• Query cache: repeated queries hit the LRU cache, skipping the entire recall/rerank/expansion pipeline (v1.5.0+)
• Incremental indexing: only changed files are processed; re-indexing is 10x+ faster
• Batch embedding: adaptive batch size with concurrency control
• Rate-limit recovery: automatic backoff on 429 errors, gradual recovery
• Connection pool reuse: pooled Tree-sitter parsers
• File index caching: lazy-loaded file-path index in GraphExpander
• Zero-cost metadata tools: list-files/find-references/get-symbol-definition do not call the Embedding API (v1.5.0+)

📈 Statistics & Observability (v1.5.0+)

contextweaver stats outputs three sections:

• Indexing process: cumulative index run count, last index time, last-run snapshot (added/modified/deleted/unchanged/skipped/errors + vector index details)
• Search quality/behavior: cumulative queries, cache hit rate, actual compute runs, plus average per-stage latency (retrieve / rerank / expand / pack) and average recalled seed count
• Health/consistency: file count and total content size, LanceDB vector row count, embedding dimensions, index version, migration state, pending_marks, language breakdown

When an abnormal migration state, pending_marks backlog, or missing vector rows are detected, the report appends diagnostic warnings with the corresponding fix commands. The --json output maps to StatsReport for scripts and monitoring systems.

🐛 Logging & Debugging

Log file location: ~/.contextweaver/logs/app.YYYY-MM-DD.log

Set the log level:

# Enable debug logging
LOG_LEVEL=debug contextweaver search --information-request "..."

🚨 Troubleshooting (v1.4.0+)

LanceDB Migration Stuck (aborted state)

Symptom: contextweaver index errors with "LanceDB is in the aborted state, refusing to write to prevent schema pollution."

Cause: during the v1.4.0 upgrade, the old LanceDB index's display_code differs from the current files.content by >1% on sampling (typically on legacy indexes whose chunk offsets used the UTF-8 byte domain).

Fix:

contextweaver migrate --reset   # Clear the LanceDB chunks table + reset state to done
contextweaver index             # Full rebuild (new schema)

You can also run contextweaver stats first to view diagnostic warnings and confirm the current migration state and pending_marks backlog.

Cross-Process Migration Race

If the MCP server is long-running and another terminal runs contextweaver index, the two processes contend for migration. v1.4.0 introduces an advisory lock with a 10-minute zombie threshold, automatically letting one process skip migration while the other completes it.

If the lock gets stuck (after kill -9), clear it manually:

sqlite3 ~/.contextweaver/<projectId>/index.db \
  "DELETE FROM metadata WHERE key = 'lancedb_migration_lock';"

Wasted Duplicate Embeddings

v1.4.0 solves this via the pending_marks outbox: when an FTS write succeeds but the vector_index_hash mark fails, it is replayed automatically on the next launch, avoiding duplicate embeddings.

Search Results Don't Reflect Recent Changes

Confirm incremental indexing has run (or enable contextweaver watch for automatic increments). The query cache key is bound to the index version, so old cache entries invalidate automatically after an index update — no manual clearing needed.

📄 License

This project is licensed under the MIT License.

🙏 Acknowledgements

• Tree-sitter - high-performance syntax parsing
• LanceDB - embedded vector database
• MCP - Model Context Protocol
• Source - Source repository

---
